Logo ICad Patterns

System that allows making the pattern, scaling and calculation of consumption of a model.

Design

Design the climbing lines of the model creating the corresponding pieces

Scale

Scaling the model, using customizable scaling systems with scaling corrections

Export

Export scaled pieces to different cutting formats

Calculate

Perform the calculation of the consumption of materials of the model
Ventajas de usar ICad Patterns

Advantages

  • The system has advanced tools that facilitate the engineering of the pattern of the model, such as turns, symmetries, margins, etc .; and all of them depend on the climbing lines.
  • It allows the use of all scaling systems and has easy-to-apply modifiers that allow any type of scaling correction to be made.
  • Multi-machine system that allows exporting to different cutting machines without the need to modify the model.
  • Consumption calculation system integrated and dependent on the lines and parts of the model.

Request more information
